Basic Info.
Model NO. | YW-L |
environment Temparture | -20ºC-50ºC |
Air Relative Humidity | <=90% |
Altitude | GB755-2000 |
Driving Type | Hydraulic Driving |
Transport Package | Wooden Box with Economy-Size Package |
Specification | driving device with hydraulic working oil |
Trademark | HONGQIAO |
Origin | China |
HS Code | 8431499900 |
Production Capacity | 16000/Year |
Product Description
1) Introduction: The industrial brake mode of YW-L is such a two-stage braking device that can coordinate function smoothly. Namely, after the first stage braking stops, the second stage braking can subsequently increase the braking torque and realize reliable maintenance braking or air release braking. It has been levered up quality control as per the standard corresponded to the crane drum brake.2) Criterion: The installation dimension of the brake shall comply with DIN15435 and JB/T7021-2006 standards, and the technical requirements shall comply with JB/T6406-2006 standards.3) Service conditions: Ambient temperature: - 20 ºC - 50 ºC; There shall be no flammable, explosive and corrosive gases in the surrounding working environment, otherwise the anti-corrosion products shall be used; The relative humidity of the air is not more than 90%; The altitude of the use site conforms to GB755-2000.4) Structure diagram:5) Technical data: Unit: mmModel | Braking torque (Nm) | Setback(mm) | M | A | b | C | D | d | E | F | G1 | G2 | H | h1 | i | K | n | Weight(kg) | |
Brake model | Matched with | ||||||||||||||||||
YW-L200/E23 | Ed23/5 | 200 | 0.6 | 165 | 215 | 70 | 160 | 200 | 14 | 180 | 100 | 165 | 75 | 710 | 160 | 55 | 145 | 10 | 46 |
YW-L200/E30 | Ed30/5 | 300 | 255 | 210 | 705 | 52 | |||||||||||||
YW-L250/E23 | Ed23/5 | 260 | 0.8 | 225 | 310 | 90 | 160 | 250 | 18 | 230 | 110 | 200 | 100 | 795 | 190 | 65 | 180 | 12 | 53 |
YW-L250/E30 | Ed30/5 | 380 | 790 | 61 | |||||||||||||||
YW-L250/E50 | Ed50/6 | 700 | 190 | 140 | 865 | 69 | |||||||||||||
YW-L315/E23 | Ed23/5 | 290 | 1.0 | 255 | 350 | 110 | 160 | 315 | 18 | 275 | 120 | 245 | 135 | 895 | 230 | 80 | 220 | 14 | 72 |
YW-L315/E30 | Ed30/5 | 410 | 890 | 78 | |||||||||||||||
YW-L315/E50 | Ed50/6 | 720 | 190 | 145 | 970 | 81 | |||||||||||||
YW-L315/E80 | Ed80/6 | 1200 | 92 | ||||||||||||||||
YW-L400/E30 | Ed30/5 | 390 | 1.25 | 280 | 370 | 140 | 160 | 400 | 22 | 340 | 160 | 310 | 150 | 955 | 280 | 100 | 270 | 14 | 98 |
YW-L400/E50 | Ed50/6 | 750 | 440 | 190 | 1075 | 102 | |||||||||||||
YW-L400/E80 | Ed80/6 | 1250 | 114 | ||||||||||||||||
YW-L400/E121 | Ed121/6 | 1900 | 240 | 1065 | 132 | ||||||||||||||
YW-L500/E50 | Ed50/6 | 900 | 1.25 | 350 | 435 | 180 | 190 | 500 | 22 | 400 | 200 | 365 | 185 | 1245 | 340 | 130 | 325 | 21 | 154 |
YW-L500/E80 | Ed80/6 | 1650 | 159 | ||||||||||||||||
YW-L500/E121 | Ed121/7 | 2500 | 240 | 1235 | 176 | ||||||||||||||
YW-L500/E201 | Ed201/7 | 4100 | 181 |
