Electro

Basic Info.

Model NO.	YWZ13
Origin	China
HS Code	8431499900
Production Capacity	30000/Year

Product Description

1) Concise introduction: This type is such a steelmaking equipment that not only enjoys a unique selling points, but also possesses research&development capability, which has the preference for large customer's offer. Having been retrofitted with latest materials, this type of brake will witness heavy enquiries in the near future.2) Selling points:

elevatable in operating position

secure in loading capacity

steady in stability

high in loading and unloading efflciency

steady in wear resistance3) Instruction for use: Having the no-load test run for the molding parts after installing the constructional elements, then the brake is naturally into the working state; Making the brake matched with thruster, reset the spring and regrind the braking pad if necessary.4) Using condition: Ambient temperature: - 20 ºC - 50 ºC; The relative humidity of the air is not more than 90%; The altitude of the use site conforms to GB755-2000; There shall be no flammable, explosive and corrosive gases in the surrounding working environment, otherwise, anti-corrosion products shall be used.5) Basic techncial data: Unit: mm

Type		braking torque (Nm)	Setback (mm)	A	B	C	D	d	E	F	Gi	G2	H/ Hmcx	hi	i	k	M	n	L	G3	Weight (kg)
Brake	Matched with
YWZ13-200/E23	Ed23/5	100-200	0.7	470	90	160	200	17	175	100	210	265	510	170	60	175 (190)	140	8	150	75	32
YWZ13-200/E30	Ed30/5	140-315																			43
YWZ13-300/E30	Ed30/5	250-400	8	590	140	160	300	22	255	130	295	330	605	240	80	250 (270)	180	12	170	135	65
YWZ13-300/E50	Ed50/6	400-630		630		190															80
YWZ13-300/E80	Ed80/6	630-1000																			92
YWZ13-400/E50	Ed50/6	400-800	1.2	710	180	190	400	22	310	180	350	420	755	320	130	325	220	14	170	150	120
YWZ13-400/E80	Ed80/6	630-1250																			130
YWZ13-400/E121	Ed121/6	1000-2000		700		240							813/830								150
YWZ13-500/E80	Ed80/6	800-1600	1.2	810	200	240	500	22	380	200	405	535	900	400	150	380	280	16	180	205	220
YWZ13-500/E121	Ed121/6	1250-2500		800									900/920
YWZ13-500/E201	Ed201/6	2000-4000
YWZ13-600/E121	Ed121/6	1800-2800	1.3	925	240	240	600	26	470	220	500	600	1080	475	170	475	340	20	185	240	305
YWZ13-600/E201	Ed201/6	2500-4500
YWZ13-600/E301	Ed301/6	4000-6500
YWZ13-700/E201	Ed201/6	2500-5600	1.3	980	280	240	700	34	530	270	570	650	1290	550	200	540	380	25	220	300	425
YWZ13-700/E301	Ed301/6	4000-8000
YWZ13-800/E301	Ed301/12	12500	2.0	1230	320	240	800	34	600	310	670	830	1430	600	240	620	420	34	240	310	545

Note: The right to change the specific model and structure dimensions is reserved.6) Sales volume:

This type of crane thrustor brake has bulit up substantial sales in this year and it will experience a further and gradual increase soon.7) Place of delivery:

It is in agreement with the place of production and process.

8) Date of delivery:

Since the delivery time is prime to customers, we will call on our workers to do overtime to try to advance shipment a little early.

9) Our service: The quality of our products are up to standard and identical with the contract stipulation; We are in charge of replacing the defective products if you find it not workable or unacceptable; We can provide you with the indication of price based on the internationally expanding market; We can offer free samples for your evaluation if you take great interest and enthusiasm in this type of brake.
